Install Arch with encrypted root + swap and UKI

I wanted an Arch setup where both root and swap stay encrypted, resume works, and systemd-boot loads a unified kernel image (UKI). This is the exact flow I used on a blank NVMe drive.

Layout used below: /dev/nvme0n1p1 (EFI, 512M), /dev/nvme0n1p2 (LUKS swap), /dev/nvme0n1p3 (LUKS root, Btrfs). Swap lives on its own LUKS volume so hibernation resumes from encrypted space.¹

Partition, encrypt, and mount

Create three GPT partitions with cfdisk or parted. For the EFI slice, set the partition type to EFI System (GUID type EF00) and toggle the esp/boot flag; formatting alone is not enough.² Then format it:

mkfs.fat -F32 -n EFI /dev/nvme0n1p1

Encrypt swap and root, then open them:³

cryptsetup luksFormat /dev/nvme0n1p2           # swap
cryptsetup luksFormat /dev/nvme0n1p3           # root
cryptsetup open /dev/nvme0n1p2 cryptswap
cryptsetup open /dev/nvme0n1p3 cryptroot

Remember that the password for root and swap must be same especially if you want to use hibernate.

Format and mount:

mkswap /dev/mapper/cryptswap
swapon /dev/mapper/cryptswap

mkfs.btrfs /dev/mapper/cryptroot
mount /dev/mapper/cryptroot /mnt
btrfs subvolume create /mnt/@
btrfs subvolume create /mnt/@home
umount /mnt

mount -o noatime,ssd,compress=zstd,space_cache=v2,discard=async,subvol=@ /dev/mapper/cryptroot /mnt
mkdir -p /mnt/{home,boot,efi}
mount -o noatime,ssd,compress=zstd,space_cache=v2,discard=async,subvol=@home /dev/mapper/cryptroot /mnt/home
mount /dev/nvme0n1p1 /mnt/efi

Base system

pacstrap -K /mnt base base-devel linux linux-firmware btrfs-progs sudo vim networkmanager plymouth
genfstab -U /mnt >> /mnt/etc/fstab
arch-chroot /mnt

Drop plymouth if you don't want a splash

Inside the chroot, set time, locale, hostname, and users:

ln -sf /usr/share/zoneinfo/Region/City /etc/localtime
hwclock --systohc
echo "en_US.UTF-8 UTF-8" >> /etc/locale.gen
locale-gen
echo "LANG=en_US.UTF-8" > /etc/locale.conf
echo "nexus" > /etc/hostname
passwd
useradd -m -G wheel xero && passwd xero
EDITOR=vim visudo   # enable wheel sudo
systemctl enable NetworkManager

systemd-boot and UKI

Install systemd-boot to the EFI partition we mounted at /efi:

bootctl install --esp-path=/efi

Use systemd-style hooks for mkinitcpio so the initramfs aligns with UKI boot:

sed -i 's/^HOOKS=.*/HOOKS=(base systemd plymouth autodetect microcode modconf kms keyboard keymap sd-vconsole block sd-encrypt filesystems fsck)/' /etc/mkinitcpio.conf

Again drop plymouth if you don't want splash screen

Preset to emit a UKI (edit /etc/mkinitcpio.d/linux.preset):

# /etc/mkinitcpio.d/linux.preset
ALL_kver="/boot/vmlinuz-linux"

PRESETS=('default')

default_image="/boot/initramfs-linux.img"
default_uki="/efi/EFI/Linux/arch-linux.efi"

Write the kernel command line to /etc/kernel/cmdline with your own UUIDs from blkid:⁴

rd.luks.name=root-uuid=cryptroot root=/dev/mapper/cryptroot rd.luks.name=swap-uuid=cryptswap rootflags=subvol=@ rw resume=/dev/mapper/cryptswap

Plymouth splash (optional but works with UKI)

Inside the chroot, add quiet splash to /etc/kernel/cmdline next to your LUKS/resume args. The hook order above already puts plymouth before sd-encrypt; just regenerate initramfs when you change the cmdline:

mkinitcpio -P
bootctl update

Zswap (optional)

If RAM is tight or you want compressed swap, add these to /etc/kernel/cmdline on the same line as the LUKS/resume args (spaces between each item):

zswap.enabled=1 zswap.shrinker_enabled=1 zswap.compressor=lz4 zswap.max_pool_percent=30 zswap.zpool=zsmalloc rd.luks.name=swap-uuid=cryptswap

Build and keep entries fresh:

mkinitcpio -P
bootctl update
systemctl enable systemd-boot-update.service

Verify and reboot

• bootctl list shows the UKI entry (and kernel version) you expect.
• /efi/EFI/Linux/arch-linux.efi exists with a fresh timestamp.
• Reboot: enter the LUKS passphrase, watch Plymouth if enabled, land on @, and check that hibernate/resume works from the encrypted swap by using this command:

sudo systemctl hibernate

Footnotes

1. Arch Wiki: Swap ↩

2. Arch Wiki: EFI system partition ↩

3. Arch Wiki: Dm-crypt/Encrypting an entire system ↩

4. Arch Wiki: Power management/Suspend and hibernate ↩
